Javaコードの利用元をたどる検索手法DKB：構文木から作るグラフの効果と費用

Reliable Graph-RAG for Codebases: AST-Derived Graphs vs LLM-Extracted Knowledge Graphs

Retrieval-Augmented Generation for software engineering often relies on vector similarity search, which captures topical similarity but can fail on multi-hop architectural reasoning such as controller to service to repository chains, interface-driven wiring, and inheritance. This paper benchmarks three retrieval pipelines on Java codebases (Shopizer, with additional runs on ThingsBoard and OpenMRS Core): (A) vector-only No-Graph RAG, (B) an LLM-generated knowledge graph RAG (LLM-KB), and (C) a deterministic AST-derived knowledge graph RAG (DKB) built with Tree-sitter and bidirectional traversal. Using 15 architecture and code-tracing queries per repository, we measure indexing time, query latency, corpus coverage, cost, and answer correctness. DKB builds its graph in seconds, while LLM-KB requires much longer graph generation. LLM-KB also shows indexing incompleteness: on Shopizer, 377 files are skipped or missed, reducing embedded chunk coverage and graph size compared to DKB. End-to-end cost is modest for DKB relative to the vector-only baseline but much higher for LLM-KB, especially as repository scale increases. Query latency is similar for No-Graph and DKB, while LLM-KB is slower and more variable. On the Shopizer question suite, DKB achieves the highest correctness, LLM-KB is close behind, and the vector-only baseline performs worst on upstream architectural queries and has the highest hallucination risk. Overall, deterministic AST-derived graphs provide more reliable coverage and multi-hop grounding than LLM-extracted graphs at substantially lower indexing cost.
