LiDARの投影で混ざる奥行きを保つRaSFNet、光線方向と走査順序を領域分割へ反映

RaSFNet: Ray-aligned and Scan-aware Fusion Network for LiDAR Semantic Segmentation

LiDAR point cloud semantic segmentation is a fundamental component of 3D perception for autonomous driving and robotics. Projection-based methods map 3D point clouds into 2D representations for feature extraction using 2D networks. However, aggregating multiple points during projection can obscure geometric differences within each frustum, while local feature extraction limits the modeling of spatial relationships across scanning regions. Moreover, proximity in the projected representation does not necessarily imply proximity in 3D space, and interactions between point and projected features may mix features from different ranges, reducing semantic discriminability. To address these challenges, we propose the Ray-aligned and Scan-aware Fusion Network (RaSFNet), which incorporates point cloud geometry and LiDAR scanning characteristics into projection-based semantic segmentation. Specifically, the Ray-Aligned Geometric Distribution Encoding (RAGDE) module characterizes point distributions within each frustum using a ray-aligned coordinate system. To model spatial context, a Scan-Topology-Aware Mamba (STAM) block organizes frustum features according to the LiDAR azimuth sampling pattern and captures long-range dependencies across scanning regions. In addition, a Range-Constrained Point-Frustum Fusion (RCPFF) mechanism uses shared range information to guide feature exchange between point and frustum representations while maintaining spatial correspondence. RaSFNet achieves mIoU scores of 70.2% and 77.7% on the SemanticKITTI and nuScenes validation sets, respectively, indicating competitive segmentation performance compared with the evaluated methods.
